EN 660-2 Resilient Floor Coverings -Determination of Wear Resistance - Part 2: Frick-Taber Test-Incl
EN 660-2 ESILIENT FLOOR COVERINGS - DETERMINATION OF WEAR RESISTANCE PART 2: FRICK-TABER TEST
EN 660-2 ESILIENT FLOOR COVERINGS - DETERMINATION OF WEAR RESISTANCE PART 2: FRICK-TABER TEST - Scope
This European Standard describes the Frick-Taber method for determining the wear resistance of the wear layer of polyvinyl chloride floor coverings under laboratory conditions The test method is applicable to floor coverings with smooth surfaces. It can be used to determine the wearresistance of surfaces against abrasion and particularly for ranking different wear layer types within onetype of product. It is not appropriate for comparing the wear resistance of different materials, e.g. rubberand polyvinyl chloride.
EN 660-2 ESILIENT FLOOR COVERINGS - DETERMINATION OF WEAR RESISTANCE PART 2: FRICK-TABER TEST–test method:
Weigh the sample accurately to ±0.1mg.
Grind one sample at 5000 RPM, pause and weigh after every 1000 RPM, and test the other 2 samples. If the first sample is worn at 5000 RPM, exclude and test the remaining 2 samples at 200 RPM/cycle until stopped after 2000 RPM or the sample is worn.
Calculate the average mass loss. Fm, represented by mg/100 turn Fm=Ftot/n*100
The mass loss of 100 revolutions per sample is calculated as follows：
Fv=Fm/ρ
characteristic | Wear resistance rating | |||
Value of loss Fv(mm3)/100turn | T | P | M | F |
Fv≤2.0 | 2.0≤Fv≤4.0 | 4.0≤Fv≤7.5 | 7.5≤Fv≤15.0 | |
working：10-12working day
sample：100x100mm* 5PCS
We also can work for you: NEW!!
EN 13501-1 Fire classification of construction products and building elements-Part1: Classification using data from reaction to fire tests
ISO 9239-1:Reaction to fire tests for floorings
EN ISO 10582:Resilient floor coverings —Heterogenous poly(vinyl chloride) floor covering EN 12825:Doppelboeden Raised Access Floors Planchers sureleves
EN 717-1:Determination of formaldehyde release - Part 1: Formaldehyde emission by the chamber method
EN 660-2:Wear group classification
ASTM F1913-04(2010):Standard Specification for Vinyl Sheet Floor Covering Without Backing
ASTM F1303-04(2009):Standard Specification for Sheet Vinyl Floor Covering with Backing
GB 8624 Classification for burning behavior of building materials and products
...
